EC-1

• KABA MAS V-52 Electronic Combo
  • Allows 1 user and 1 master
  • Self-generating power
  • 1 super master combination/2 user combinations
  • 6 digit access
    • Users choose their own changeable combination
  • Dual custody
    • 2-person integrity (requires 2 users to open lock)
  • Manager/user operation
    • Allows manager to add, delete, enable, or disable an additional user
  • Numerical keypad
  • Quick entry
  • Wrong try lockout
    • The lock will not allow access to any user for 3 minutes after 5 incorrect combinations entered
    • Any additional consecutive failed entry attempts will result in another 3-minute lockout

EC-2

• KABA MAS V-252 Self-Powered Electronic Lock (252SVN10N4AE1A)
  • Allows multiple users
  • No batteries needed (relies on generated power)
  • 1 super master, 1 master, and up to 20 user combinations
    • Includes 2-digit user ID and 6-digit user-selected PIN
  • Supervisor and subordinate mode
    • Allows access by a subordinate only after being enabled by a supervisor
    • When enabled, the subordinate user has access to the lock during valid opening times
  • Dual custody
    • 2-person integrity (requires 2 users to open the lock)
  • Numerical keypad
  • Quick entry
  • Wrong try lockout
    • The lock will not allow access to any user for 3 minutes after 5 incorrect combinations entered
    • Any additional consecutive failed entry attempts will result in another 3-minute lockout

EC-8

• KABA MAS V-552
  • Electronic

EC-Apexx

• Axessor Apexx
  • One key pad controls up to 16 lock boxes
  • IP capable and hardwired
  • Motorized Dead and Latch Bolt options
  • Duress alarm feature
  • Dual user mode
  • Time Lock
  • Wrong try penalty
  • Remotely updatable firmware

EC-701

• La Gard Electronic Combo Model 701
  • Deadbolt style
  • 1 master, 1 manager
  • No dual mode

EC-702

• La Gard Electronic Model 702
  • Deadbolt style
  • 1 master, 28 users, 1 manager
  • Dual mode available
  • 500 audit events

EC-702D

• La Gard Electronic Combo Model 702D
  • Deadbolt style
  • 1 master, 28 users, 1 manager
  • Dual mode available
  • 500 audit events
  • 1.28″ monochrome OLED display, 128×64

EC-703

• La Gard Electronic Combo Model 703
  • Deadbolt style
  • 1 master, 28 users, 1 manager
  • Dual mode available
  • 500 audit events
  • 1.28″ monochrome OLED display, 128×64

EC-703B

• La Gard Electronic Combo Model 703
  • Deadbolt style
  • 1 master, 28 users, 1 manager
  • Dual mode available
  • 500 audit events
  • 1.28″ monochrome OLED display, 128×64

EC-704

• La Gard Electronic Combo Model 704
  • Deadbolt style
  • 1 master, 47 users, 2 managers
  • Dual mode available
  • 2000 audit events
  • 1.28″ monochrome OLED display, 128×64

EC-705

• La Gard Electronic Combo Model 704
  • Deadbolt style
  • 1 master, 97 users, 2 managers
  • Dual mode available
  • 6000 audit events
  • 1.28″ monochrome OLED display, 128×64

C-1

• S&G, Mechanical, Group II, 3 Wheel Combo, 6730 Series
  • Black, spy-proof dial

C-2

• S&G, Mechanical, Group II, 3 Wheel Combo, 6730 Series
  • Key-locking dial
  • Black, spy-proof dial

EC-3

• S&G, Electronic, Model 6123
  • 3 modes of operation
    • Single user, dual control, manager/employee
• 7 codes available
  • 1 master, 1 supervisor, 5 user
• Management reset code
• Motor-driven
• EMP-resistant
• Time delay
  • 1-99 minutes
• Penalty lock

EC-4

• S&G, Electronic, Model 6126-142
  • Motor-driven
  • Dead-latching design for superior security
  • Snap-In touch key reader assures accurate audit data transfer
  • Time/date event audit trail helps with security procedure compliance
  • PC-based, easy-to-use audit trail software (purchased separately)
  • Captures last 400 lock operations in audit trail
  • Up to 30 users and flexible user programming
  • Supervisor/user, dual control, and multiple user modes
  • Time Delay
    • 1 -99 minutes
  • Silent duress alarm (requires optional duress module).
  • Requires 2, 9-volt batteries located in keypad

EC-11

• S&G, Electronic, Titan
  • Three modes of operation
    • Single user, dual control, manager/employee
  • Ten codes
    • Programmer, master, user
    • Management reset code when in single control mode
  • Time delay override code
  • EMP-resistant
  • Quick, easy installation
  • Penalty lockout

EC-10

• AMSEC, Electronic, ESL10XL
• Each key is individually backlit
• Factory Reset Combination
  • Resolves lost combinations without requiring expensive service calls
• Electronics are encapsulated within the lock and are sealed to prevent possible moisture-related failures
• Cable fits through a ½” spindle hole without cutting and re-crimping connector
• Beep and flash from every keystroke gives maximum feedback to the user
• Lock can be programmed to silence the beep in stealth mode
• 15-Minute Penalty Lockout after four incorrect entries
• Swing bolt reversible lock design for right- or left-handed installation
• Lock “auto-locks” when bolt work is thrown to prevent safes from being left open.
• One 9-volt battery can be easily replaced in the keypad housing

EC-20

• AMSEC, Electronic, ESL20XL
• Each key individually backlit
• Factory Reset Combination
  • Resolves lost combinations without requiring expensive service calls
• Electronics are encapsulated within the lock and are sealed to prevent possible moisture-related failures
• Cable fits through a ½” spindle hole without cutting and re-crimping connector
• Beep and flash from every keystroke gives maximum feedback to the user
• Lock can be programmed to silence the beep in stealth mode
• 15-Minute Penalty Lockout after four incorrect entries
• Swing bolt reversible lock design for right- or left-handed installation
• Lock “auto-locks” when bolt work is thrown to prevent safes from being left open
• One 9-volt battery can be easily replaced in the keypad housing

EC-12

• Pulse Pro Straight Bolt, Electronic Combo Lock
  • T6630DLGRP-Pulse Pro keypad with key reader and rubber membrane keypad
  • T3300-rotating back plate
  • T4800DM4-Pulse Pro straight bolt lock with threaded M4 bolt
  • Satin Chrome or Black Metal Keypad
  • Rubber Membrane
  • Keypad or PC programmable
  • Keypad and battery level tests
  • Time delay (1-99 minutes)
  • Open Window (1-19 minutes)
  • Up to 10 Override Users
  • Up to 2 master codes, 3 manager codes, 59 user codes
  • Dual token capability (User can be code only/key only/code & key)
  • Optional silent alarm (requires battery/alarm box)
  • Optional remote disable opening (requires battery/alarm box)
  • Door open alarm
  • Bolt status output
  • Emergency Rescue Code (ERC)
  • Resettable 5,500 event time/date stamped audit trail

EC-14

• Pulse PLUS Straight Bolt Combo Lock
  • Black metal keypad
  • Keypad programmable (2 user/10 user and single/dual mode)
  • Keypad test
  • Time delay (1-99 minutes)
  • Open window (1-19 minutes)
  • Override user (10-user program only)
  • Dual token capability (user code and E-key required)
  • Optional silent alarm (requires battery/alarm box)
  • Optional remote disable opening (requires battery/alarm box)
  • 100 event audit trail (no time/date)
  • Resettable
  • Available mechanisms: RotoBolt (swing bolt), straight bolt (deadbolt), and spring bolt

EC-17

• LP Locks, “EM35-50 + KBL-50-BK + W024”
  • 1 manager / 9 users
  • Programmable time delay
    • Time delay override
  • Dual control mode available
